USB-A Smart Card Reader ACS ACR40T-A1

ACR40T-A1 – SIM-Sized Smart Card Reader (USB Type-A)

The ACR40T-A1 is a modern, fast contact smart card reader from ACS, designed in a SIM-sized format and equipped with a USB Type-A connector. The device supports firmware updates, allowing it to remain compliant with evolving security and integration requirements without the need to replace hardware.

Its main design feature is a sliding card slot, which makes card insertion easier and helps protect the card during transport. The ACR40T-A1 supports ISO 7816 Class A, B, and C cards (5 V, 3 V, 1.8 V) as well as microprocessor cards operating with T=0 and T=1 protocols. Thanks to compliance with CCID, PC/SC, and Microsoft® WHQL certification, integration with operating systems is simple and seamless.

Main applications

• PKI / electronic signature

• e-banking and payments

• authentication and access control

• SIM-sized integrations (mobile solutions requiring a compact form factor)

Key features

• USB Type-A connector (USB 2.0 Full Speed)

• Support for ISO 7816 A/B/C cards (5 V / 3 V / 1.8 V)

• T=0 and T=1 protocols for microprocessor cards

• Firmware upgrade capability after deployment

• Compliance with CCID, PC/SC, and Microsoft® WHQL

• Compact and lightweight design — SIM-sized format with a sliding card slot

Technical specifications (selected)

Interface
USB Type-A (USB 2.0 Full Speed)

Supported cards
ISO 7816 Class A / B / C; microprocessor cards (T=0, T=1); memory cards

Compliance
CCID, PC/SC, Microsoft® WHQL

Dimensions (product)
4.89 × 1.78 × 0.8 cm

Net weight
0.007 kg

Customs tariff code
8471607000

Typical use cases: PKI tokens, electronic signature, SIM-sized authentication, mobile integrations.
